Ceramic Miniature Cartridge Fuse , 1000 Amp Fuse ISO8820 Standard

Name: Ceramic Miniature Cartridge Fuse 1000 Amp Fuse ISO8820 Standard
Brand: Dissmann
Price: 1 USD

Buy cheap Ceramic Miniature Cartridge Fuse , 1000 Amp Fuse ISO8820 Standard product

Brand Name : Dissmann

Model Number : DKN-A

Certification : UL

Place of Origin : China

MOQ : 100pcs

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 1,000,000pcs

Delivery Time : 5-8days

Packaging Details : Standard Carton Packing

Material : Ceramic

Colour : Blue,Yellow,Red,Green

Rated Voltage : 32VDC

Rated Current : 2A-30A

Breaking Capacity : DC1KA

Standard : UL248、ISO8820、ROHS

Usage : Automotive

Keyword : Automotive fuse

Contact Now

32volt Dc Fuse Low Current Fuse Mini Cartridge Fuse 1KA DC Fuse

Material:
Noumenon: Ceramic
Pins: Copper alloy

Features:

Mini Cartridge Fuse

Many kinds of Mini Cartridge Fuse
Current rating:2A-30A
Voltage rating: 32VDC

Breaking capacity:DC1KA

Product Presentation:

Rated Voltage

32VDC

Characteristic

Fast Blowing

Rated Current

2A-30A

Breaking Capacity

DC1000A

Meet the Requirement

UL248,ISO8820,

EU and Rosh Directive

Remarks

Overall dimensions of the product(mm)

Current characteristic curve of Ceramic Miniature Cartridge Fuse

Ceramic Miniature Cartridge Fuse , 1000 Amp Fuse ISO8820 Standard

Product type of Ceramic Fuse

Model	Product code	Rated current	I²t	Voltage drop	Pigment
Model	Product code	Rated current	(A²Sec)	Voltage drop	Pigment
DKN-A	DKN-A-2	2	2.8	170	(Gray)
	DKN-A-3	3	9.3	152	(Violet)
	DKN-A-4	4	17	120	(Pink)
	DKN-A-5	5	24	128	(Tan)
	DKN-A-7.5	7.5	66	135	(Brown)
	DKN-A-10	10	92	108	(Red)
	DKN-A-15	15	270	98	(Blue)
	DKN-A-20	20	380	96	(Yellow)
	DKN-A-25	25	620	85	(Clear)
	DKN-A-30	30	1120	86	(Green)

Performance criteria

Test current item(A)	Current	Minimum time(s)	Maximum time(s)
110%	2A-30A	360000	∞
135%	2A-30A	0.75	600
200%	2A-30A	0.15	5
350%	2A-30A	0.08	0.5
600%	2A-30A	0.03	0.1

Test equipment

Ceramic Miniature Cartridge Fuse , 1000 Amp Fuse ISO8820 Standard

Production equipment
